| Part Number | Description |
| YV-DVIU1V1A-T/R | Uncompressed 1ch DVI with loop-out+1ch BiDi audio(3.5mm) |
| YV-DVIU1V1A↑↓D3-T/R | Uncompressed 1ch DVI with loop-out+1ch BiDi audio(3.5mm)+1ch RS232 Data |
| YV-DVIU1V1A↑↓D3K-T/R | Uncompressed 1ch DVI with loop-out+1ch BiDi audio(3.5mm)+1ch RS232 Data+1ch USB1.1 |
* Transmits DVI video signals up to 10km over one fiber op tic cable;
* Support video resolution up to 1920* 1080@60hz
* Support keyboard and mouse signal transmission;
* Support external stereo audio unidirectional transmission;
* Support RS232 signal unidirectional transmission, baud rate self adaptive;
* Compliance with DVI 1.0 and HDCP 1.2 standard;
* High compatibility, can auto match source and display device;
* Built in automatic adjustment system, make the image smooth, clear and stable;
* Built in ESD protection system;
* Simple to install, plug and play;
