| Part Number | Data Rate | Wavelength | LD | Power Supply | Tx Power(dBm) | Rx Sens | Reach |
| 155Mb/s Dual Fiber | |||||||
| YV-1x9FE-1 | 155Mbps | 850nm | FP | 3.3/5V | ≥-18dBm | ≤-28dBm | 1km |
| YV-1x9FE-5 | 155Mbps | 1310nm | FP | 3.3/5V | ≥-18dBm | ≤-34dBm | 5km |
| YV-1x9FE-20 | 155Mbps | 1310nm | FP | 3.3/5V | ≥-14dBm | ≤-33dBm | 20km |
| YV-1x9FE-40 | 155Mbps | 1310nm | FP | 3.3/5V | ≥-11dBm | ≤-33dBm | 40km |
| YV-1x9FE-60 | 155Mbps | 1310nm | FP | 3.3/5V | ≥-5dBm | ≤-35dBm | 60km |
| YV-1x9FE-80 | 155Mbps | 1550nm | DFB | 3.3/5V | ≥-8dBm | ≤-36dBm | 80km |
| YV-1x9FE-100 | 155Mbps | 1550nm | DFB | 3.3/5V | ≥-3dBm | ≤-36dBm | 100km |
| YV-1x9FE-120 | 155Mbps | 1550nm | DFB | 3.3/5V | ≥-1dBm | ≤-37dBm | 120km |
| 155Mbps Single Fiber | |||||||
| YV-1x9FE-5T | 155Mbps | T1310/R1550nm | FP | 3.3/5V | ≥-18dBm | ≤-33dBm | 5km |
| YV-1x9FE-5R | 155Mbps | T1550/R1310nm | DFB | 3.3/5V | ≥-18dBm | ≤-33dBm | 5km |
| YV-1x9FE-20T | 155Mbps | T1310/R1550nm | FP | 3.3/5V | ≥-14dBm | ≤-33dBm | 20km |
| YV-1x9FE-20R | 155Mbps | T1550/R1310nm | DFB | 3.3/5V | ≥-14dBm | ≤-33dBm | 20km |
| YV-1x9FE-40T | 155Mbps | T1310/R1550nm | FP | 3.3/5V | ≥-11dBm | ≤-33dBm | 40km |
| YV-1x9FE-40R | 155Mbps | T1550/R1310nm | DFB | 3.3/5V | ≥-10dBm | ≤-33dBm | 40km |
| YV-1x9FE-60T | 155Mbps | T1310/R1550nm | FP | 3.3/5V | ≥-5dBm | ≤-35dBm | 60km |
| YV-1x9FE-60R | 155Mbps | T1550/R1310nm | DFB | 3.3/5V | ≥-10dBm | ≤-35dBm | 60km |
| YV-1x9FE-80T | 155Mbps | T1490/R1550nm | DFB | 3.3/5V | ≥-8dBm | ≤-36dBm | 80km |
| YV-1x9FE-80R | 155Mbps | T1550/R1490nm | DFB | 3.3/5V | ≥-8dBm | ≤-36dBm | 80km |
| YV-1x9FE-100T | 155Mbps | T1490/R1550nm | DFB | 3.3/5V | ≥-3dBm | ≤-36dBm | 100km |
| YV-1x9FE-100R | 155Mbps | T1550/R1490nm | DFB | 3.3/5V | ≥-3dBm | ≤-36dBm | 100km |
| YV-1x9FE-120T | 155Mbps | T1490/R1550nm | DFB | 3.3/5V | ≥-1dBm | ≤-37dBm | 120km |
| YV-1x9FE-120R | 155Mbps | T1550/R1490nm | DFB | 3.3/5V | ≥-1dBm | ≤-37dBm | 120km |
* Standard +3.3V /+5V Power Supply
* SC/FC/ST and pigtail optical interface
* Standard TTL data output with signal detect indication, compatible with CMOS leve
* Standard 1x9 package
* Super low power consumption, applied to some special requirement
* Optional transmission bit rate with down to Obps and up to 10Mbps
* SC/FC/ST and pigtail optical interface
* Standard TTL data output with signal detect indication, compatible with CMOS leve
* Standard 1x9 package
* Super low power consumption, applied to some special requirement
* Optional transmission bit rate with down to Obps and up to 10Mbps
