800G Series

800G is a hot-pluggable optical transceiver that adopts 100G PAM4 modulation technology, including 4x100Gx2 and 8X100G architecture solutions to meet the short-distance transmission needs of data centers. The range of products is compliant with IEE802.3ck and supports CMIS 5.0. The products are mainly used in 800G Ethernet, data center and cloud networks.

Send Enquiry

Order Model
Specifications

P/N	Data Rate	Reach	Tx	Rx	Interface
YV-800GOSFP-SR8	800G	100m	850nm VCSEL	PIN	MPO-16
YV-800GOSFP-VR8	800G	50m	850nm VCSEL	PD	MPO-16
YV-800GOSFP-DR8	800G	500m	1310nm EML	PIN	MPO-16
YV-800GOSFP-DR8+	800G	2km	1310nm EML	PIN	MPO-16
YV-800GOSFP-DR8++	800G	10km	1310nm EML	PIN	MPO-16
YV-800GOSFP-2xVR4	800G	50m	850nm VCSEL	PIN	MPO-16
YV-800GOSFP-2xFR4	800G	2km	CWDM EML	PIN	Dual LC
YV-800GOSFP-2xLR4	800G	10km	CWDM EML	PIN	Dual LC
YV-800GQDD800-SR8	800G	100m	850nm VCSEL	PIN	MPO-16
YV-800GQDD800-DR8	800G	500m	1310nm EML	PIN	MPO-16
YV-800GQDD800-DR8+	800G	2km	1310nm EML	PIN	MPO-16
YV-800GQDD800-DR8++	800G	10km	1310nm EML	PIN	MPO-16
YV-800GQDD800-2xFR4	800G	2km	CWDM EML	PIN	Dual CS
YV-800GQDD800-2xLR4	800G	10km	CWDM EML	PIN	Dual CS
YV-800GQDD-VR8	800G	50m	850nm VCSEL	PD	MPO-16

* ≤14W Low Power Consumption
* Transmission data rate up to53.125Gbit/s per channel
* Hot Pluggable OSFP MSA Compliant
