| P/N | Data Rate | Wavelength | Reach | Connector | Tx Power | Rx Sensitivity | Source |
| YV-QSFP28-ZR4 | 100Gbps | LAN-WDM | 80km | Dual LC | -2~6.5db | ≤-28db | EML+APD |
* Compliant with 100GBASE-ZR4
* Support line rates from 103.125 Gb/s to 111.81 Gb/s OTU4
* LAN WDM EML laser and PIN receiver with SOA
* Up to 80km reach for G.652 SMF
* Hot pluggable 38 pin electrical interface
* QSFP28 MSA compliant
* Duplex LC optical receptacle
* RoHS-10 compliant and lead-free
* Single +3.3V power supply
* Maximum power consumption 6.5W
* Case operating temperature Commercial: 0 ~ +70℃
* Support line rates from 103.125 Gb/s to 111.81 Gb/s OTU4
* LAN WDM EML laser and PIN receiver with SOA
* Up to 80km reach for G.652 SMF
* Hot pluggable 38 pin electrical interface
* QSFP28 MSA compliant
* Duplex LC optical receptacle
* RoHS-10 compliant and lead-free
* Single +3.3V power supply
* Maximum power consumption 6.5W
* Case operating temperature Commercial: 0 ~ +70℃
