| Part Number | Data Rate | Port | |||||
| YV-MCFE-SFP | 10/100Mbps | 1SFP and 1RJ45, support 155Mbps SFP Module | |||||
| YV-MCGE-SFP | 10/100/1000Mbps | 1SFP and 1RJ45, support 1.25Gbps SFP Module | |||||
* Max. 2M buffer memory built in chip.
* Auto negotiation back pressure flow control for full duplex IEEE802.3 X and half duplex.
* Automatic identification of MDI/MDI-X cross line
* High-performance 1.4Gbps memory bandwidth.
* LED display for PWR,link/activity, full/half duplex,100M,1000M
* Forward 1600 bytes packet for management;
* max. transmission distance can be 120km;
